IR Tunnel Conveyor dryer SD12000

Model No.︰

SD12000

Brand Name︰

LC

Country of Origin︰

China

Unit Price︰

US $ 12995 / pc

Minimum Order︰

1 pc

Share on:

Product Description

Description:

 IR Drying tunnel  for variety of screen printing, pad printing and spraying thermosetting ink processing such as heat press, electric products, ( silicon, electric membrane film key press, window glass. )
 This conveyor dryer is widely used in the drying of screen printing industry,is especially suitable for solidifying heat-set and special type of printing ink.This  tunnel dryerenables the production of printed products with good colorfastness, high flexibility and high gloss.


Features:

1. Intelligent temperature control system,easy operation,can control of temperature deviation effective.

2. Adopt hot circulating system,save energy effectivly.

3. Teflon screen belt , customers' designs are welcome

4. Far infrared heating pipe is especially suitable for solidifying heat-set and special type of printing ink.

5. Adjustable belt speed and tunnel temperature controls.

6. Cooling System with Ten fans.

7. Insulation cotton for Heat area box.

8. Galvanized iron bracket: 2pcs

Parameters:

Temperature range

Normal~200º C

Enterrance length

1.90M .

Exit length

0.80M.

Drying box area

8M length .

Cooling hood

1M

Space between drying zone and cooling zone

0.30M

Conveyor total length

12M.

Conveyor width

1M.

Belt material

2*2.5mesh glass fiber Teflon

Enter high

120mm.

Leg high

375mm

Working Power Supply

AC 380V 50HZ

Belt speed adjustment

0-30M/MIN

Package dimensions

288*144*120CM

Package weight

430KG



Price Terms︰ FOB ShenZhen, China
Packing︰ WOODEN CASE
Lead Time︰ 28 DAYS AFTER PAYMENT
Standards Certificate︰ CE
Application area︰ drying plastic products, metal ink, spary painting ink, solvent ink, IR drying tunner
Gross Weight︰ 430kg
Main Parts︰ ceramic heating tube & quartz heating tube

Product Image
