Automatic Single Cylinder UV Screen Printer

Model No.︰

LCB-120UV-1

Brand Name︰

LC

Country of Origin︰

China

Unit Price︰

US $ 25000 / unit

Minimum Order︰

1 unit

Share on:

Product Description

 Full  Automatic One Colour Cylinder Screen Printer LCB-120UV-1.
This auto printing press system is specially used for printing different patterns on the objects with round shape or oval shape. As it is made up of several individual units to form a printing chain, it can be used for the purpose of one-color printing. The materials to be printed can be plastic, glass, ceramics, metal, etc

 https://www.youtube.com/watch?v=INSuwso_VcU

1. MAIN MOTOR: SITI(Italy)
2. PLC: Omron(
Japan)
3. SENSOR: Optex(
Japan)
4...TOUCH SCREEN: Proface(
Japan)
5. Switch: Schneider(
France)
6. (CONTACTOR): (Schneider)(
France)
7(RELAY): (Idec)(
Japan)
8. (INVERTER): Omron(
Japan)
9. (UV CURING)(Primarc brand uv lamp )
Britain
10. (PNEUMATIC): Festo(Germany)



1 Model NoLCB-120UV-1
2Printing colors1 color
3.Product appearance:Round bottle /  oblate bottle
4OperationFull Auto
5min printing diameterround bottle: 20 mm
6max printing diameterround bottle :100 mm
7min printing radiusoblate bottle :25 mm
8max printing radiusoblate bottle :260 mm
9oblate bottle width20-100 mm
10oblate bottle thickness20-80 mm
11Max Printing speed4000-5000Pcs/Hr
12Power380V
13Weight1050(kg)

14.DimensionsL:1900×W:1000×H:1500(mm)



1-COLOUR AUTO SCREEN PRINTER

Model No

LCB-120UV-1

LCB-150UV-1

LCB-350UV-1

Printing colors

1 color

1 color

1 color

Product appearance

Round bottle

 oblate bottle

Round bottle

 oblate bottle

Round  bottle



Operation

Full Auto

Full Auto

Full Auto

min printing diameter(round bottle)

20 mm

20 mm

150 mm

Max printing diameter(round bottle)

100 mm

150 mm

350 mm

min printing radius

(oblate bottle)

25mm

25mm

/

max printing radius

(oblate bottle)

260mm

300mm

/

oblate bottle width

20-80 mm

20-100 mm

/

Max Printing speed

4000-5000Pcs/Hr

4000-5000Pcs/Hr

2000Pcs/Hr

Power

380V

380V

380V

Weight

1050kg

1360kg

1550kg





1.Full automatically printing suitable to print on various shades of cylindrical, elliptical and falt workpieces;

 2.Coupled with auto workpiece feeding and loading system;

3.Flame treatment device adopted for re-treatment on PE or PP workpieces to get ultimate ink adhesion;


4.The function of workpiece placing in advance is built-in aiming on cylindrical or elliptical printing;


5.Electric sensor creates "no workpiece no printing" that leads to intelllgent monitor and smart control;


6.High quality UV curing system adopted to ensure fast ink drying and color registration;


7.High printing speed that up to 4000pcs/hr will bring you with high productivity;


8.Conveniently and easily fixture adjustment and change that save your valuable time;


9.Multi-sets of this machine can achieve 2-color, 3-color and even 4-color auto printing system..





Price Terms︰ EXW,dongguan ,china
Packing︰ wooden case
Lead Time︰ 25 days after deposit
Standards Certificate︰ CE
Application area︰ package of cosmetic, lipstick, bottles.
Gross Weight︰ 1300KG
Main Parts︰ 1. MAIN MOTOR: SITI(Italy) ,3. SENSOR: Optex(Japan)
Free Fittings ︰ SILK SCREEN PLATE ,SQUEEGEE,
