MINI Toptable System FLAT Silk Screen Printing Machine
Suitable for printing on various materials such as wood, plastic, metal, glass, leather, cosmetics, gifts, or ceramic etc.Be widely used in electronic industry, advertising, packing & printing, sports equipment, toy, stationery, gifts, industrial arts fields etc...
Printing objects such as decal, cards, transfer paper, pester, sticker, PVC/PET/PC films, metal nameplate etc which are made of non-deforming materials
1. Advanced computerized system control
2. Built-in LED digital counter
3. Light-weight, strong aluminum cast machine frame
5. Can be operated in manual and semi-auto mode to suit different worker's skill level.
6. Horizontal movement of screen frame can be adjusted to fit your various printing needs.
7. Squeegee/flood bar depth, pressure, speed, leveling, and stroke etc., are all adjustable to fit your various printing needs.
1. Thickness of printing matter: 0~80mm
2. Size of printing table：300×500mm
3. Max printing area：250×350mm
4. Max Stroke of up-and-down frame：125mm
5. Max. printing speed：2000pcs/hour
6.Air pressure：6 Bar
Power voltage: 110V/220V 50Hz
Power consumption：35 W
Machine weigh: 85Kg
Package dimensions: 80*75*120CM
Package weight: 140KG
