Description:
Servo rotary two-color machine is an automatic screen printing machine used in flat sheet brush, with high precision drive, idling platform, servo control system, servo printing and servo lifting system stable and reliable, easy to debug, easy to operate. This Machine for variety of plastic crate,box,Oblong Box.
Features:
1、Automatic two-color printing mode job
2、The rotating mechanism adopts servo and hollow rotating platform.
3、This machine module assembly line, 2 stations printing.
4、Servo printing drive, high efficiency, high precision, you can set the printing parameters.
5、Screen printing process: manual feeding - flame treatment - first screen printing station -LED curing - 180 rotation - Second screen printing station -LED curing - back to the loading level
6、There are 8 modes that can be set, rotary four-sided and single-sided, double-sided printing
Parameters:
1、Printing Speed : 1-3pcs/min
2、Printing left and right stroke : 650mm
3、Air Pressure : 0.6-0.8Mpa
4、Power : 7kw
