Servo system CNC Cylindrical Screen Printer For Water Bottle

Model No.︰

LC-PA-600ES

Brand Name︰

LC

Country of Origin︰

China

Minimum Order︰

1 SET

Share on:

Product Description

LC-PA-600ES screen printer add servo system for color registration. The machine should be PLC contorl, left and right by servo system, the frame move by electric, roating by servo system, do not need gear,with color sensor too.

LC-PA-600ES adopted 2 set ABB Swiss Servo Motor, German Leuze color sensor and Japan Hitachi PLC system. One servo is for Screen movement, another servo is for Fixture rotation. And the German Leuze color sensor is used to recognized the print position. It make sure to accurate position of products and no need to adjustment .

It's suitable for bottles, cups, tubes and etc.

Here is the video show the machine working:

https://www.youtube.com/watch?v=LeqLbbZv3xM

https://www.youtube.com/watch?v=VgZC_Y4pNhQ

Suitable for precise printing substrates in Cylindrical,  forms whic h with smooth curve surface and made of various materials such as metal, plastic, ceramic, glass, wood etc...Printing objects such as lipstick, cosmetic bottles, scour bottles, drink bottles, pots, oil-filter shell etc...
Cylinder screen printers can print one color at one time. Once replacing frame and ink, they can print 2, 3^colors.


Parameter:

1. Model number: LC-PA-600ES

2. 2 set ABB SwissServo Motor and PLC.

3. Germany LEUZE Brand Color sensor.

4. Product appearance: Round

5. (Round)Max. Printing diameter: Φ180mm

6. (Round)Max printing arc length: L: 570mm

7. Printing Speed: 2000 PC/H

8. Machine/ Weight: 320kg

9. Machine/ gross weight: 360kg

10. Air pressure: 0.5Mpa

11. Voltage power:220V/ 50HZ

Package dimensions: 124*113*174

Package weight: 325kg


Advantages
1. Round printing function (taper section)
2. Automaticoil scrabbing, oil return and lifting table
3. Adujustability of routs and speeds
4. Self-poise scraper to balance printing pressure
5. Adjustable table (fluctuation & round) and netting easel (fluctuation & both sides)
6. High precision and easy & quick adjustability



Testing Please provide:
1. 380V power supply.
2. 5-7 bar compress air.
3. Esposal screen plate 1 pcs.
4. A jig 1pcs.
5. 5-10 pcs product samples.


Application area detergent bottles, Pens, beverage bottles, cups, cans, cosmetics package box, lipstick tube





Auto Uv Screen Printer

Full Servo Automatic Silk Screen Printing Machine

Logo Screen Printer Printing Machine

Logo Screen Printer Printing Machine

Bottle Cup Logo Curved Screen Printing Machine

Logo Screen Printer Printing Machine

Logo Screen Printer Printing Machine

Perfume Bottle Jar Logo Screen Printer

Auto Cylindrical Screen Printer For Water Bottle

Bottle Cup Logo Curved Screen Printing Machine

Bottle Cup Logo Curved Screen Printing Machine

Auto Cylindrical Screen Printer For Water Bottle

Logo Screen Printer Printing Machine

Logo Screen Printer Printing Machine

Glass Uv Printing Machine



Price Terms︰ EXW DONGGUAN CHINA
Packing︰ PLYWOOD CASE
Lead Time︰ 15 DAYS AFTER PAYMENT
Standards Certificate︰ CE
Application area︰ bottles ,
Gross Weight︰ 325kg
Main Parts︰ FUJI Sevor
H.S.code︰︰ 8443198000
