2-color open ink well pad printing machine with conveyor with rotary system

Model No.︰

LC-PM2-150/16

Brand Name︰

LC

Country of Origin︰

China

Unit Price︰

US $ 7800 / pc

Minimum Order︰

1 pc

Share on:

Product Description

2-color pad printer with conveyer
1.2-colour pad printer with shuttle driven by cylinder
2. Each function controlled by microprocessor for easy operation
3. High quality aluminum alloy is used to make structure solid and light weight
4. Ink roller is used for ink covering, so it is easy to clean, install and uninstall
5. Independent pad up/down stroke and speed adjustment
6. Auto balanced doctor blade available for efficient ink scraping
7. Printing speed adjustable to fulfil various requirements
8. Inking twice, printing once" function for thick ink film
9. Able to sweep forward/backward without lowering pad to avoid ink drying at intervals
10.2-colour and 1-colour printing available
11. Drying with auto air blowing for easy color registration

Specifications

Operation

Semi-Automatic

No. of color

2 color

Working station

16 Pcs

Working table area

90×125mm

Standard plate area

100×150mm

Max printing speed

1800 Pcs/Hr

Power voltage

220V/50Hz

Power consumption

50 W

Air pressure

6 Bar

Air consumption

300 Liter/Min

Machine dimension

980×710×1420 mm

Machine weight

200Kg

2 color bottle cap pad printing machine plasma
shoe two colors pad printing machine with shuttle
4color shuttle pad printing machine
Tampografica Pad Printing Machine
neck label pad printing machine
perfume bottle pad printing machine
tampo printing machine
pad printing machine pvc
shoe logo pad printing machine
led bulb pad printing machine
garment label pad printing machine
hard hat pad printing machine
super primex pad printing machine
ink cup pad printing machine
professional electronic single color printing pad
mini pad printing machine semi-automatic use
garment pad printing machine
pad printing machines for round applications
eraser pad printing machines
shoe pad printing machine
insole pad printing machine


Price Terms︰ FOB Shenzhen , China
Packing︰ Wooden case
Lead Time︰ 35 Days
Standards Certificate︰ CE
Application area︰ PLASTIC SPARE PARTS
Gross Weight︰ 200kg
