LC-120AL-1 Automatic Screen Printing Line

Model No.︰

LC-120AL

Brand Name︰

LC

Country of Origin︰

China

Unit Price︰

US $ 23000 / unit

Minimum Order︰

1 unit

Share on:

Product Description

https://www.youtube.com/watch?v=JWetR3DYk2E

LC-120AL-1 it is a full mechanical conveyer, With the touching control panel operation, easy to operate the machine. Fast adjustment, easy operation. Fast printing, speed: 4000pcs/hr

The following is the machine main parts

1. MAIN MOTOR: SITI(Italy)
2. PLC:  Omron(Japan)
3. SENSOR: Optex(Japan)
4. TOUCH SCREEN: Proface(Japan)
5. Switch: Schneider(France)
6. (CONTACTOR):(Schneider)(France)
7.(RELAY): (Idec)(Japan)
8. (INVERTER): Omron(Japan)
9. (UV CURING)(Primarc)Britain
10. (Cylinder):Festo(Germany)

Product Information:

1.The machine is specialized design for printing the round or oval bottles, with easy operation and stable.
2. Feeding machine can load product to the screen printing machine automatically..fully automatic feeding, flame treatment, UV screen printing and UV curing.
3. It is a mechanical conveyer ,With touching control panel operation , easy to operate the machine. Fast adjustment, easy operation. Fast printing,speed:4000pc/hr.
4. Fully automatic,It will alarm when the machine without product loading and no printing without product. it can save energy.
5. All components and control system are from Germany and Japan, guarantee the quality of the print.
6. It is suitable for print round/oval product printing such as the cosmetic bottles, drink bottles, cans ect
Specification:

Subject surface

Oval

Round

Max speed

4000pcs/hr

3600pcs/hr

Max print length

120mm

270mm

Max print wide

250mm

250mm

The size of print

semimeter:Φ25-Φ260mm

diameter:Φ25-100mm

Length :60-270mm

Length :60-270mm

The power of UV lamp

4Kw/unit

UVair draft power

0.2KW

reduction gearbox Conveyer proportion

1:7.5

Single motor power

0.75KW

The power ofbottle liftervacuum motor

0.5KW

Vacuum supply

500 mmAq

Flame treatment fuel

LPG

air supply

6Bar

Air consumption

400Liter/Min

Power supply

AC380V  3Phase  50Hz

Package dimensions:  267*146*216CM
                                    219*80*172CM

       Package weight:   1470KG



Price Terms︰ EXW,dongguan ,china
Packing︰ plywood case
Lead Time︰ 30days after confirm payment
Standards Certificate︰ CE
Application area︰ round bottles
Gross Weight︰ 1470kg
Main Parts︰ 1. MAIN MOTOR: SITI(Italy) 2. PLC: Omron(Japan)
Free Fittings ︰ screen frame, fixture,English manual, tool box
H.S.code︰︰ 8443198000

Product Image
